Description
MUTUAL NON-WOVENS | |||||||||
---|---|---|---|---|---|---|---|---|---|
Uses | NW35 | NW40 | NW45 | NW60 | NW80 | NW100 | NW120 | NW160 | |
Subsurface Drainage | X | X | X | X | X | Non-woven geotextiles used as a filter, allow subsurface water to pass into drainage core while preventing soil from clogging the system | |||
Drainage Systems | X | X | X | X | When placed in contact with a Geonet or drainage stone non-woven geotextiles can filter soil and waste while alloing water and waste to pass | ||||
Liner Protection | X | X | X | X | Non-woven geotextiles protect liners from damage by sharp objects, elevating puncture impact and abrasion resistance | ||||
Asphalt Overlay | X | X | X | X | Absorb asphalt tack to form moisture barrier that retards reflective cracking |
||||
Railroad Stabilization | X | X | X | Putting a non-woven geotextile directly on a soft saturated subgrade extends road and rail life by preventing aggregate and ballast from intermixing with soil | |||||
Erosion Control | X | X | X | X | Non-woven geotextiles can help relieve hydrostatic pressure beneath hard armour and prevent subsurface soils from migrating through the erosion control system | ||||
Roadway Stabilization | X | X | X | Putting a non-woven geotextile directly on a soft saturated subgrade extends road and rail life by preventing aggregate and ballast from intermixing with soil | |||||
Waste Management | X | X | Non-woven geotextiles are used to separate layers and to protect liners in the landfills |
Mutual Non-Woven Specifications | NW35 | NW40 | NW45 | NW60 | NW80 | NW100 | |
---|---|---|---|---|---|---|---|
Grab Tensile Strength | ASTM D-4632 | 90 lbs | 105 lbs | 120 lbs | 165 lbs | 215 lbs | 270lbs |
Grab Elongation | ASTM D-4632 | 50% | 50% | 50% | 50% | 50% | 50% |
Trapezoid Tear | ASTM D-4533 | 35 lbs | 45 lbs | 50 lbs | 90 lbs | 85 lbs | 100 lbs |
Puncture | ASTM D-4833 | 55 lbs | 60 lbs | 65 lbs | 90 lbs | 115 lbs | 150 lbs |
Mullen Burst | ASTM D-3786 | 185 PSI | 210 PSI | 230 PSI | 310 PSI | 360 PSI | 450 PSI |
Permitivity | ASTM D-4491 | 2.2 SEC-1 | 2.2 SEC | 1.5 SEC-1 | 1.5 SEC | 1.0 SEC | .7 SEC |
Permeability | ASTM D-4491 | .2 CM/SEC | .2 CM/SEC | .25 CM/SEC | .2 CM/SEC | .25 CM/SEC | .25 CM/SEC |
A.O.S. | ASTM D-4751 | .21 US Sieve | 70 US Sieve | 70 US Sieve | 80 US Sieve | 80 US Sieve | 100 US Sieve |
Water Flow | ASTM D-4491 | 110 gpm/ft2 | 150 gpm/ft2 | 120 gpm/ft2 | 80 gpm/ft2 | 65 gpm/ft2 | 55 gpm/ft2 |
U.V. Resistance (500 hr) | ASTM D-4355 | 70% | 70% | 70% | 70% | 70% | 70% |
Weight (oz/sq yd) | ASTM D-5261 | 3.5 oz | 4 oz | 4.5 oz | 6 oz | 8 oz | 10 oz |
